SKU: HDA,GX120-QXC9
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Honda GX120 QXC9 Horizontal OHV Engine with Cyclonic Air Filter, 122cc, 3.2 Net HP, 3/4" x 2-7/16" Crankshaft
Product specifications for Honda GX120 QXC9 Horizontal Engine with Cyclonic Air Filter
| Engine Information |
| Brand |
Honda |
| Model Number |
GX120-QXC9
|
| Warranty |
3 Year Residential | 3 Year Commercial
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
42.0 lb |
| Power |
| Power Output |
3.2 HP @ 3600 RPM
|
| Torque |
5.4 lb-ft (7.3 Nm) @ 2500 rpm
|
| Crankshaft |
| Orientation |
Horizontal
|
| Type |
Straight
|
| Diameter |
3/4"
|
| Length |
2-7/16"
|
| Dimensions |
3/4" x 2-7/16"
|
| End Tapped Size |
5/16"-24
|
| Keyway Width |
3/16"
|
| Rotation Direction |
Counter-Clockwise
|
| Other Engine Specifications |
| Starter Type |
Recoil
|
| Ignition System |
Transistorized Magneto
|
| Carburetor |
Butterfly
|
| Number of Cylinders |
One
|
| Cylinder Bore |
Cast Iron Sleeve
|
| Air Cleaner |
Cyclone
|
| Oil Capacity |
0.59 qt
|
| Fuel |
Unleaded 86 Octane or Higher
|
| Fuel Tank Capacity |
2.1 qt
|
| Fuel Pump |
N/A
|
| Governor System |
Mechanical
|
| Bore x Stroke |
60mm x 43.5mm
|
| Compression Ratio |
8.3 : 1
|
