SKU: HDA,GX25-T3
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Honda GX25 T3 Mini 4-Stroke OHC Engine, 25cc, 1.0 Net HP, Vertical Application, Manual Throttle and Choke Control, Diaphragm Carburetor, Model GX25NTT3
Product specifications for Honda GX25 T3 Mini 4-Stroke Engine, Vertical Application
| Engine Information |
| Brand |
Honda |
| Model Number |
GX25-T3
|
| Warranty |
2 Year Residential | 1 Year Commercial
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
10.0 lb |
| Power |
| Power Output |
1.0 HP @ 7000 RPM
|
| Torque |
0.74 lb-ft @ 5000 RPM
|
| Crankshaft |
| Orientation |
Vertical
|
| Rotation Direction |
Counter-Clockwise
|
| Other Engine Specifications |
| Starter Type |
Recoil
|
| Ignition System |
Transistorized Magneto
|
| Carburetor |
Diaphragm (Overflow Return)
|
| Number of Cylinders |
One
|
| Air Cleaner |
Semi-Dry
|
| Oil Capacity |
2.7 oz
|
| Fuel |
Unleaded 86 Octane or Higher
|
| Fuel Tank Capacity |
0.61 qt
|
| Bore x Stroke |
35mm x 26mm
|
| Compression Ratio |
8.0 : 1
|
