SKU: HDA,GXV160-N1MH
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Honda GXV160 N1MH Vertical OHV Engine, 163cc, 4.3 Net HP, 7/8" x 3.14" Crankshaft, Tapped 3/8-24 UNF, 5/32" Key, OHV, Remote Controls
Superseded / Replaced by: Honda GXV160-N1XH
Product specifications for Honda GXV160 N1MH Vertical Engine
| Engine Information |
| Brand |
Honda |
| Model Number |
GXV160-N1MH
|
| Warranty |
2 Year Residential | 2 Year Commercial
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
40.0 lb |
| Power |
| Power Output |
4.3 HP @ 3600 RPM
|
| Torque |
7.1 lb-ft (9.6 Nm) @ 2500 rpm
|
| Crankshaft |
| Orientation |
Vertical
|
| Type |
Straight
|
| Diameter |
7/8"
|
| Length |
3.14"
|
| Dimensions |
7/8" x 3.14"
|
| End Tapped Size |
3/8"-24"
|
| Keyway Width |
5/32"
|
| Rotation Direction |
Counter-Clockwise
|
| Other Engine Specifications |
| Starter Type |
Recoil
|
| Ignition System |
Transistorized Magneto
|
| Carburetor |
Float Type
|
| Number of Cylinders |
One
|
| Air Cleaner |
Dual Element
|
| Oil Capacity |
0.69 qt
|
| Fuel |
Unleaded 86 Octane or Higher
|
| Fuel Tank Capacity |
0.98qt
|
| Fuel Pump |
N/A
|
| Governor System |
Centrifugal Mechanical
|
| Controls |
Remote (Rod) Choke & Throttle
|
| Bore x Stroke |
68mm x 45mm
|
| Compression Ratio |
8.0 : 1
|
