SKU: KOH,PA-CH440-3282
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler CH440-3282 Horizontal OHV Command PRO Engine with 6:1 Gear Reduction, 1" Crankshaft, M8 x 1.25 Tapped, 429cc, 14 Gross HP, 22.7 ft lbs Torque, Recoil and Electric Start with 18 Amp Charging
Product specifications for Kohler CH440-3282 Horizontal Command PRO Engine, 6:1 Gear Reduction, Replaces CH440-3049
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-CH440-3282
|
| Warranty |
3 Year Limited
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
73.0 lb |
| Power |
| Max RPM |
3750
|
| Crankshaft |
| Orientation |
Horizontal
|
| Type |
Gear Reduction
|
| Diameter |
1.00"
|
| Length |
74.3mm
|
| Dimensions |
1.00" x 74.3mm
|
| End Tapped Size |
M8 x 1.25
|
| Other Engine Specifications |
| Starter Type |
Recoil & Electric
|
| Ignition System |
Electronic
|
| Number of Cylinders |
One
|
| Cylinder Bore |
Cast Iron Liner
|
| Air Cleaner |
Quad Clean Heavy Duty Cyclonic
|
| Oil Capacity |
1.4 qt
|
| Fuel |
Gasoline
|
| Fuel Tank Capacity |
7.4 qt
|
| Controls |
Manual & Remote for Z-bend connection only (cable connection requires additional parts) Throttle, Manual Choke
|
| Bore x Stroke |
3.5" x 2.7"
|
| Compression Ratio |
8.3 : 1
|
| Charging System |
18 Amp
|
| Engine Notes |
6:1 gear reduction with electric start and 18 amp charging
|
