SKU: KOH,PA-CV752-3012
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler CV752-3012 Vertical OHV Command PRO Engine, 747cc, 1.125" x 4.3" Crankshaft, 27 Gross HP, 41.2 ft lbs Torque, 20 Amp Charging, E16 Bad Boy Mowers Spec, Replaces CV750-3033, CV750-0014 and CV750-0033
Product specifications for Kohler CV752-3012 Vertical Command PRO Engine, Replaces CV750-3033
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-CV752-3012
|
| Warranty |
3 Year Limited
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
120.0 lb |
| Power |
| Crankshaft |
| Orientation |
Vertical
|
| Diameter |
1.125"
|
| Length |
4.3"
|
| Dimensions |
1.125" x 4.3"
|
| Other Engine Specifications |
| Starter Type |
Electric
|
| Number of Cylinders |
Two
|
| Cylinder Bore |
Cast Iron Liners
|
| Air Cleaner |
Heavy Duty
|
| Oil Capacity |
2.0 qt
|
| Fuel |
Gasoline
|
| Bore x Stroke |
3.3" x 2.7"
|
| Compression Ratio |
9.1 : 1
|
| Charging System |
20 Amp
|
| Engine Notes |
E16 Bad Boy Mowers spec
|
