SKU: KOH,PA-KT740-3088
Barcode:
5.0 / 5.0 based on 1 review
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler KT740-3088 Vertical V-Twin 7000 Series Engine, 1" x 3.16" Crankshaft, 7/16"-20 Tapped, 1/4" Full Keyway, Bendix Drive Electric Start, 25 Max HP, 725cc, 41.3 ft lbs Torque, RFI Ignition, HPAC, E16 Ariens Spec, Replaces KT740-3067, KT740-3056 and KT740-3054
Replaced by PA-KT745-3103
Product specifications for Kohler KT740-3088 Vertical 7000 Series Engine, Replaces KT740-3067
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-KT740-3088
|
| Warranty |
3 Year Limited
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
91.0 lb |
| Power |
| Max RPM |
3600
|
| Crankshaft |
| Orientation |
Vertical
|
| Diameter |
1"
|
| Length |
3.16"
|
| Dimensions |
1" x 3.16"
|
| End Tapped Size |
7/16"-20
|
| Other Engine Specifications |
| Starter Type |
Bendix Drive Electric
|
| Number of Cylinders |
Two
|
| Cylinder Bore |
Cast Iron Liners
|
| Air Cleaner |
High Profile
|
| Oil Capacity |
2.0 qt
|
| Fuel |
Gasoline
|
| Controls |
Dual
|
| Bore x Stroke |
3.3" x 2.6"
|
| Compression Ratio |
9.1 : 1
|
| Charging System |
Yes
|
| Engine Notes |
E16 Ariens spec
|
