SKU: KOH,PA-KT745-3014
Barcode:
5.0 / 5.0 based on 1 review
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler KT745-3014 Vertical V-Twin 7000 Series Engine, 1" x 3.16" Crankshaft, Bendix Drive Electric Start with 15 Amp Regulator, 26 Max HP, 747cc, 42.4 ft lbs Torque, Low Profile Air Cleaner, E09 Husqvarna Spec, Replaces SV735-3021, SV735-0013 and SV735-0017
Replaced by PA-KT745-3002
Product specifications for Kohler KT745-3014 Vertical 7000 Series Engine, Replaces SV735-3021
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-KT745-3014
|
| Warranty |
3 Year Limited
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
91.0 lb |
| Power |
| Max RPM |
3300
|
| Crankshaft |
| Orientation |
Vertical
|
| Diameter |
1"
|
| Length |
3.16"
|
| Dimensions |
1" x 3.16"
|
| Other Engine Specifications |
| Starter Type |
Bendix Drive Electric
|
| Number of Cylinders |
Two
|
| Cylinder Bore |
Cast Iron Liners
|
| Air Cleaner |
Low Profile
|
| Oil Capacity |
2.0 qt
|
| Fuel |
Gasoline
|
| Controls |
Dual
|
| Bolt Circle |
None
|
| Bore x Stroke |
3.3" x 2.7"
|
| Compression Ratio |
9.1 : 1
|
| Charging System |
15 Amp Regulator
|
| Engine Notes |
E09 Husqvarna spec
|
