SKU: KOH,PA-CH730-3210
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler CH730-3210 Horizontal OHV Command PRO Engine, 1-1/2" x 3.94" Tapered Crankshaft, 725cc, 23.5 HP, V-Twin, Electric Start with 15 Amp Charging and Key Switch Installed, Image may not reflect exact details of specific engine model, Replaces PA-68504, PA-CH730-0108
Replaced by PA-CH730-3005
Product specifications for Kohler CH730-3210 Horizontal Command PRO Engine, Replaces CH730-0108
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-CH730-3210
|
| Warranty |
3 Year Limited
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
108.0 lb |
| Power |
| Max RPM |
2400
|
| Crankshaft |
| Orientation |
Horizontal
|
| Type |
Tapered
|
| Diameter |
1-1/2" Tapered
|
| Length |
3.94"
|
| Dimensions |
1-1/2" Tapered x 3.94"
|
| Other Engine Specifications |
| Starter Type |
Electric
|
| Carburetor |
Two-Barrel
|
| Number of Cylinders |
Two
|
| Cylinder Bore |
Cast Iron Liners
|
| Air Cleaner |
Flat
|
| Oil Capacity |
2.0 qt
|
| Fuel |
Gasoline
|
| Bolt Circle |
5-5/8", 7-3/4"
|
| Bore x Stroke |
3.3" x 2.7"
|
| Compression Ratio |
9.1 : 1
|
| Charging System |
15 Amp
|
| Engine Notes |
Basic E3 spec
|
