SKU: KOH,PA-SH265-3021
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler SH265-3021 Horizontal OHV Single-Cylinder Engine, 0.75" x 2.46" Crankshaft, 5/16"-24 Drilled & Tapped, 12V Electric & Recoil Start with 3 Amp Charging System, Variable Speed, 6.5 Max HP, 196cc, 10.2 ft lbs Torque
Replaced by PA-SH265-3031
Product specifications for Kohler SH265-3021 Horizontal Engine with Electric Start & 3 Amp Charging
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-SH265-3021
|
| Warranty |
2 Year Consumer / 90 Day Commercial
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
45.19 lb |
| Power |
| Max RPM |
3850
|
| Crankshaft |
| Orientation |
Horizontal
|
| Diameter |
0.750"
|
| Length |
2.42"
|
| Dimensions |
0.750" x 2.42"
|
| End Tapped Size |
5/16"-24
|
| Other Engine Specifications |
| Starter Type |
12V Electric & Recoil
|
| Number of Cylinders |
One
|
| Cylinder Bore |
Cast Iron Liner
|
| Air Cleaner |
Without Foam Pre-Cleaner
|
| Oil Capacity |
0.6 qt
|
| Fuel |
Gasoline
|
| Fuel Tank Capacity |
3.4 qt
|
| Controls |
Manual & Remote Throttle, Manual Choke
|
| Bore x Stroke |
2.7" x 2.1"
|
| Compression Ratio |
8.5 : 1
|
| Charging System |
3 Amp
|
| Engine Notes |
E16 Basic spec
|
