SKU: KOH,PA-XT650-3045
Barcode:
This engine has been discontinued by the manufacturer. Give us a call if you need help finding an alternate option.
Kohler XT650-3045 Vertical OHV Single Cylinder XT Series Engine, 25mm x 3.16" Crankshaft, 0.25" Keyway, 149cc, 6.5 ft lbs Gross Torque, Fixed Speed, Recoil Start, E09 Husqvarna
Product specifications for Kohler XT650-3045 Vertical XT Series Engine, E09 Husqvarna Spec
| Engine Information |
| Brand |
Kohler |
| Model Number |
PA-XT650-3045
|
| Warranty |
2 Year Consumer / 90 Day Commercial
|
| Available to California |
Not Available to Ship to California
|
| Dimensions |
| Weight |
25.0 lb |
| Power |
| Max RPM |
3100
|
| Crankshaft |
| Orientation |
Vertical
|
| Diameter |
25mm
|
| Length |
3.16"
|
| Dimensions |
25mm x 3.16"
|
| Other Engine Specifications |
| Starter Type |
Recoil
|
| Number of Cylinders |
One
|
| Cylinder Bore |
Cast Iron Liner
|
| Air Cleaner |
Dual Seal
|
| Oil Capacity |
0.6 qt
|
| Fuel |
Gasoline
|
| Fuel Tank Capacity |
1.16 qt
|
| Controls |
Fixed Speed
|
| Bore x Stroke |
2.6" x 1.8"
|
| Compression Ratio |
9.2 : 1
|
| Charging System |
N/A
|
| Engine Notes |
E09 Husqvarna
|
